1) Remove all the contents from inside of the vacuum cleaner container
2) Attach the carry handle into the slots located on the top of the power head.
3) Turn the container upside down and insert the feet with casters into the slots and apply pressure until they click into place. Secure them with supplied screws.
4) Your vacuum cleaner comes ready for dry vacuum cleaning with the cartridge filter pre-installed.
5) Optionally, for improved dust filtration, fully fit the dust bag flange onto the inlet stub.
6) For wet vacuuming, replace the cartridge filter with the foam filter supplied. Do not use a dust bag when wet vacuuming.
7) Secure the power head back on the container, using the 2 side latches. Insert the locking end of the hose into the suction port of the container.
8) Choose the desired accessories and/or extension wands and push fit onto the hose nozzle.

Floor Nozzle Attachments

1) To remove the floor nozzle attachment, release the push clips on either side of the floor tool holder. The attachment should drop out from underneath.
2) To insert a new floor nozzle attachment, place one side of the attachment into the bottom of the floor tool holder and secure one clip in place. Push the other side up into place and ensure it is securely fitted into the holder.

1) Keep all safety devices, air vents and the motor housing free of dirt and dust. Use a soft, dry brush to clean the equipment regularly.

2) Clear all dirt or debris from the collection tank after each use. Allow to dry before replacing the power head. Do not use cleaning agents or solvents; these may damage the appliance.

3) Check the hose, attachments, and power cord to verify that they have not been damaged or any debris is trapped and blocking airflow.

Cleaning the Cartridge Filter

Remove the filter and clean by gently tapping or brushing off dirt. For optimal performance it is recommended to replace the old filter with a new filter regularly.

Cleaning the Foam Filter

Remove the foam filter and use a mild soap and water solution to wash and rinse with clean water. Allow filter to air dry before installing and using again.
